32A, 7kW Smart Wall-Mounted EV Charger

32A, 7kW single phase Type 1 or Type 2 (IEC/Mennekes) Wall-Mounted EV Charger.

Korora Tech is a registered responsible supplier under the EESS, and this equipment is registered (EESS equipment number E2025000445).

This wall-mounted EV charger offers safe, compact, and user-friendly functionality, designed for easy installation. CE Certified to meet IEC standards with supporting documentation for reliable and compliant operation.

Get competitive pricing on our EV chargers for dealers and bulk buyers. Contact us directly for exclusive pricing.

Electrical Specification:

• Input Voltage: 100V-240V (Single Phase)
• Input Frequency: 50Hz
• Max. Output Power: 7kW
• Max. Output Current: 32A

Key Features:

• 7kW, 32A Type 1 or Type 2 Wall-Mounted Charger in sleek black design
• Wi-Fi Enabled App Control (Tuya Smart) for enhanced convenience
• 4.3-inch LCD Display providing real-time data on Voltage, Amperage, Power (kW), and Energy Consumption (kWh)
• IP65 Waterproof Grade for robust outdoor performance, IK10 impact resistance
• Certified CE and RoHS
• RCD-DD (6mA DC) + RDC Type A RCD Protection
• Key cards for charging start/stop
• 5m cable

App Features:

• Start/stop control
• Delayed charging
• Schedule to charge at certain times (e.g., special night rates from power companies)
• Change the charging current (1-32A). Please note this is only adjustable when the car isn’t charging.
• View detailed charging history (energy usage and time)

Comprehensive Safety Features:

• Over-voltage protection
• Under-voltage protection
• Overload protection
• Short-circuit protection
• Earth leakage protection
• Over-temperature protection
• Lightning protection

Standards:

• EN IEC 61851-1 2019 (General Safety Requirement)
• EN IEC61851-21-2 2021 (EMC)
• IEC 62955 2018 (RCD)
• EN 62196-1 2014 (Vehicle Connectors)
• EN 62196-2 2017 (Vehicle Connectors)

1 Year Warranty.
